Waterproof LED module
Equipped with 12 LEDs, available in 2 optical circuits
LEDs
They achieve light efficiency up to 118lm / W for the luminaire
Driver Philips Xitanium
Highly efficient and programmable constant current power driver with 7 programmable functions according to customer requirements
Available functions:
- possibility to regulate the output current
- DALI interface or 1-10V (OPTION)
- programmable time profiles
- temperature control on the module
- power control of the luminaire using the output voltage
- maintaining a constant luminous flux in time
- reduction of power by connecting additional phases (OPTION)
Anodized aluminium
inox / graphite color with anticorrosive and decorative properties
Elastomer protection
For additional corrosion protection at the bottom of the column, we offer the option of covering the base-plate including holes for mounting bolts and a fragment of rolled part up to 350 mm by polyurethane elastomer.The thickness of the protective coating is within the range of 0.7 mm to 1 mm with a hardness of about 90°sh.
| Paraméter | Érték |
|---|---|
| Ingress protection | IP 65 |
| Material | anodised aluminium alloy |
| Colour | inox / graphite |
| Optical system | PMMA optics, interchangeable LED module |
| Number of LEDs | 8 for 24W; 16 for 48W |
| Expected useful lifetime | L90F10 – 50 000 h, L80F20 – 100 000 h |
| CRI | >70 for 5000K; >80 for 3500K |
| Corrective factor S/P | — for 5000K, 3500K |
| Input voltage frequency | 50 - 60Hz |
| Power factor | ≥0.95 |
| Inrush current | for 24W, 48W |
| Csatolmány | Méret |
|---|---|
 flexi-led.pdf | 106.71 KB |
| Code | Symbol | LED power | Luminaire Power consumption | Colour temperature (CCT) | Luminaire luminous flux | Luminous efficacy | Concrete footing / reinforcement basket type | Net weight |
| 215530/3/S/...1) | FLEXI 24 | 24W | 28W | 3500K | 1850lm | 67lm/W | B-50 / Z-50 | 29kg |
| 215530/3/A/...1) | FLEXI 24 | 24W | 28W | 3500K | 1725lm | 63lm/W | B-50 / Z-50 | 29kg |
| 215530/6/S/...1) | FLEXI 24 | 24W | 28W | 5000K | 2375lm | 86lm/W | B-50 / Z-50 | 29kg |
| 215530/6/A/...1) | FLEXI 24 | 24W | 28W | 5000K | 2200lm | 80lm/W | B-50 / Z-50 | 29kg |
| 215533/3/S/...1) | FLEXI 48 | 48W | 55W | 3500K | 3700lm | 67lm/W | B-50 / Z-50 | 32kg |
| 215533/3/A/...1) | FLEXI 48 | 48W | 55W | 3500K | 3450lm | 63lm/W | B-50 / Z-50 | 32kg |
| 215533/6/S/...1) | FLEXI 48 | 48W | 55W | 5000K | 4750lm | 86lm/W | B-50 / Z-50 | 32kg |
| 215533/6/A/...1) | FLEXI 48 | 48W | 55W | 5000K | 4400lm | 80lm/W | B-50 / Z-50 | 32kg |
