Overvoltage protection
Increases the immunity of the luminaire to electrical discharges up to 15 pulses at 10 kV
Driver Philips Xitanium
High-performance and constant currentpower supply with 7 programmable functions according to customer requirements .
LEDs
They achieve light efficiency up to 118 lm / W for the luminaire
Anodized aluminium body
Inox / black color with anticorrosive and decorative propertiesh
| Paraméter | Érték |
|---|---|
| Application | residential roads (internal), surrounding office buildings, parks, pedestrians |
| Assembly | on extension arms with ø60 x 100 mm ending |
| Ingress protection | IP 66 for the optical part, IP54 for the driver |
| Material | anodised aluminium alloy |
| Colour | inox / black |
| Optical system | PMMA optics |
| Number of LEDs | 12 for 36W; 16 for 48W |
| Expected useful lifetime | L90F10 – 50 000 h, L80F20 – 100 000 h |
| CRI | >70 for 5000K, 4000K; >80 for 3500K |
| Corrective factor S/P | 1,8 for 5000K; 1,45 for 3500K; 1,55 for 4000K |
| Input voltage frequency | 50 - 60Hz |
| Power factor | ≥0.95 |
| Inrush current | 46A / 250µs for 36W, 48W |
| Csatolmány | Méret |
|---|---|
 drop-led.pdf | 317.55 KB |
