Replaceable LED module
Waterproof LED module. Equipped with 24 LEDs, available in 4 optical circuits
Driver Philips Xitanium
High-performance and constant current power supply with 7 programmable functions according to customer requirements
Overvoltage protection
Increases the immunity of the luminaire to electrical discharges up to 15 pulses at 10 kV
Anodized aluminium body
Inox/graphite color with anticorrosive and decorative propertiesh
| Paraméter | Érték |
|---|---|
| Application | urban roads, residential roads (internal), parks, pedestrians |
| Assembly | on extension arms with ø60 x 100 mm ending |
| Ingress protection | IP 66 for the optical part and the driver |
| Material | anodised aluminium alloy |
| Colour | inox / graphite |
| Optical system | PMMA optics, interchangeable LED module |
| Number of LEDs | 24 for 60W |
| Expected useful lifetime | L90F10 – 50 000 h, L80F20 – 100 000 h |
| CRI | >70 for 5000K, 4000K; >80 for 3500K |
| Corrective factor S/P | 1,8 for 5000K; 1,45 for 3500K; 1,55 for 4000K |
| Input voltage frequency | 50 - 60Hz |
| Power factor | ≥0.95 |
| Inrush current | 46A / 250µs for 60W |
| Csatolmány | Méret |
|---|---|
 vega-led.pdf | 502.89 KB |
| Code | Name | LED power | Luminaire Power consumption |
Colour temperature (CCT) |
Luminaire luminous flux |
Luminous efficacy |
Net weight |
| 2141034/3/...1) | VEGA LED 60 | 60W | 67W | 3500K | 7700lm | 115lm/W | 10kg |
| 2141034/4/...1) | VEGA LED 60 | 60W | 67W | 4000K | 8000lm | 119lm/W | 10kg |
| 2141034/6/...1) | VEGA LED 60 | 60W | 67W | 5000K | 8400lm | 125lm/W | 10kg |
1) Symbol of chosen optical system eg. 2141034/6/T2 is VEGA LED 60 5000K with T2 optical system
